Simpson Strong-Tie BA5.12/20 (2-1/2" x 20") Top-Flange Joist Hanger for Double Engineered Wood

Product image 1
Product image 2
Product image 3
Product image 4

Simpson Strong-Tie BA5.12/20 (2-1/2" x 20") Top-Flange Joist Hanger for Double Engineered Wood

Simpson Strong-Tie BA5.12/20 Description

The Simpson Strong-Tie BA Beam Hanger is designed for secure connections in wood framing projects, offering high load capacity and ease of installation.

Simpson Strong-Tie BA5.12/20 Includes

  • (1) Beam Hanger

Simpson Strong-Tie BA5.12/20 Features

  • Designed for I-Joists and SCL
  • Top-Flange Installation
  • High Load Capacity
  • Versatile Application

Simpson Strong-Tie BA5.12/20 Applications

  • Floor Framing: Provides secure support for I-joists and SCL in multi-story buildings.
  • Roof Framing: Ensures stability in engineered wood roof truss and rafter connections.
  • Deck Construction: Ideal for attaching joists in covered outdoor structures.
  • Beams & Headers: Strong, load-bearing connection for supporting beams in residential and commercial builds.
  • Commercial & Industrial Projects: Suited for large-scale engineered wood framing applications requiring long-term strength and reliability.

Simpson Strong-Tie BA5.12/20 Installation Overview

  1. Use Specified Fasteners: Install with approved nails or screws to ensure maximum load capacity and structural integrity.
  2. Top-Flange Placement: Secure the hanger over the supporting beam or ledger before setting the I-joist into place.
  3. Full Contact with Member: Ensure the joist seats fully inside the hanger for proper load transfer.

Simpson Strong-Tie BA5.12/20 Specifications

Finish G90 Galvanized
Material Carbon Steel
Fasteners required Header - (16) 0.162 x 3-1/2" Nails Joist - Min: (2) 0.148 x 1-1/2" Nails - Max: (8) 0.148 x 1-1/2" Nails
Height 20"
Joist size Double 2-1/2" X 20"
Manufacturer name Simpson Strong-Tie
Quantity 1
Thickness 12 Gauge
Width 5-1/8"

NOTE: This item is made to order with varied lead times. Please contact the manufacturer for exact lead times.
